MCCB

Type

CMC-100

CMC-225

CMC-400

CMC-630

Rated current In
at 50°C ambient temperature

A

16-25-40-
63-80-100

125-160-
200-225

250-315-
350-400

500-630

Number of poles

2

3

4

2

3

4

3

4

3

4

Rated operational voltage Ue
AC 50/60 Hz
DC

V
V

690
500

690
500

690
500

690
500

Switching capacity Icu/Ics
RMS value according to IEC
60947-2
UP to 240V AC
UP to 415V AC
UP to 440V AC
UP to 500/525V AC
UP to 690V AC
UP to 250V DC

kA
kA
kA
kA
kA
kA

65/65
55/55
25/20
25/20
12/6
32/32

65/65
55/55
25/20
25/20
12/6
32/32

65/65
35/26
25/20
25/20
15/8
32/32

65/65
35/26
35/20
25/20
20/10
30/30

Rated insolation voltage Ui

V

690

690

690

690

Rated impulse withstand
voltage Uimp

KV

6

6

6

6

Rated Closing Capacity on
short circuit Icm at 415 Vac

KA

105

105

105

105

Category of use

–

A

A

A

A

Dimensions (L x H x D)
2-pole
3-Pole
4-Pole

mm

64.5x150x89
91x150x89
121x150x89

73.9x165x111
105.5x165x111
141x165x111

–
148x260x155
196.5x260x155

–
181x270x160
238x270x160

Weight
2-pole
3-Pole
4-Pole

kg
kg
kg

0.850
1.150
1.475

1.425
1.900
2.425

–
5.475
7.075

–
7.475
9.775
